600W Efficient Wind Solar Hybrid Controller for Residential , Home
1.Product name:HECO-600 Vertical Axis Maglev Wind Turbine
HECO-600 Vertical Axis Maglev Wind Turbine is a breakthrough in wind power technology. It’s Honor Eco who made magnetic levitation technology used in wind turbine for the first time. This creates a milestone and fulfills important breakthrough in the history of small and medium wind turbine development. The maglev technology improves the efficiency of wind power 35% compared to traditional horizontal axis wind turbine. The innovative wind generators have been widely used for Telecoms Base Receiver Station (BTS) as well as residential and commercial applications.
2.Environment:
• Zero emission
• Synergy with Solar and Geothermal systems
• Dual colors make it easy for bird identification in order to prevent collisions (Animal-friendly)
3.Installation:
• Easy Installation: System can be assembled within one hour
• No welding
• Single or multiple unit connection for bigger power production
• Easy connection with PV systems
4.Design:
• Gearless design: no need to replace worn-out or broken gear
• Brushless: motor brushes making high failure items results in regular replacements
• Bearing-free design: no need to lubricate or to replace worn-out bearings
• Magnetic levitation design: reduces rotational resistance to enhance power generation as well as prolong the turbine life.
• No yaw or furling mechanism required: allows for peak power output at any wind speed
• No cogging torque for cutting-in at low wind speed
• Direct-drive: Extends product life
• Blades can start rotating at very low wind velocity of 2.2 mph (1 m/s)
• Space-saving, aerodynamic airframe
• Heavy duty and industrial level construction
5.Control:
• Intelligent control system has automatic protective functions to lower rotational speed in case of so strong wind as hurricane
• Real-time remote monitoring system can monitor and acquire data and equipment performance.
6.Technical Specifications
|
Items
|
HECO600-24V
|
HECO600-48V
|
|
Rated power
|
600W
|
600W
|
|
Dimension
(Height/Diameter)
|
1500/Ø1320
|
Ø1500/1320
|
|
Weight
|
48KG
|
48 kg
|
|
Blade material
|
Aluminum Alloy
|
Aluminum Alloy
|
|
Blade quantity
|
7 (3D+4S)
|
7(3D+4S)
|
|
Swept area ㎡
|
1.36
|
1.36
|
|
Min starting wind speed
|
1m/s
|
1m/s
|
|
Cut-in wind speed
|
2.7m/s
|
2.7m/s
|
|
Rated wind speed
|
13m/s
|
13m/s
|
|
Cut-off wind speed
|
15m/s
|
15m/s
|
|
Survival wind speed
|
60m/s
|
60m/s
|
|
Generator type
|
AC,3Phases
|
AC,3Phases
|
|
Controller Output Voltage
|
24V
|
48V
|
|
Controller Braking System
|
3-phase short circuit by NFB brake
|
3-phase short circuit by NFB brake
|
